BLAZE SPECIFICATIONS
MANGUSTA 72’
LOA 22,17 mt
BEAM 5,60 mt
FUEL CAPACITY 4300 Lts
WATER CAPACITY 1000 Lts
MAX. SPEED 41Kts
CRUISE SPEED 34 Kts
COMPSUTION AT CRUISE SPEED 500 LTS/HRS
THE YACHT IS VAT PAID
MAIN ENGINE W5 SERVICED (DECEMBER 2014)
MAIN ENGINE YEARLY SERVICE CARRIED OUT (FEBRUARY 2017)
2 GENERATORS YEARLY SERVICED (FEBRUARY 2017)
ARNESON PROPELLERS 2 YEARLY SERVICED (MARCH 2016)
WATERMAKER YEARLY SERVICED (DECEMBER 2016)
NEW WATERMAKER MEMBRANES (FEBRUARY 2016)
NEW JETSKI VX V1 YAMAHA (JULY 2015)
NEW ENGINE RISERS (FEBRUARY 2017)
NEW 100 METERS ANCHOR’ S CHAIN
NEW FRIDGE BOSCH (GALLEY) FEBRUARY 2017
MAIN ENGINE 2X MTU 10V 2000 M93 CR 1120 KW AT 2450 RPM (998 hours update on MARCH 2017)
MARINE GEARS ZF 2050
SHAFT COUPLINGS RUBBER DESIGN 107 GA “S”
TRANSMISSIONS ARNESON ASD 14 BI LU
PROPELLERS ROLLA S BLADES D =39” P= 50”
GENERATORS 2X KOHLER EFOZ 17 KW 230V 50HZ (2300 hours updated MARCH 2017)
BILGE/CHAIN/FIRE PUMP GIANNESCHI ACB 331 24V
AUTOMATIC BILGE PUMPS 4 X RULE MOD.2000 24V
BLACK WATER TANK DRAIN PUMP GIANNESCHI ECO MV44 24V
GRAY WATER TANK DRAIN PUMP GIANNESCHI CP 25/I 24V
ENGINE ROOM BLOWERS/EXTRACTORS 4 X GIANNESCHI ELL/R400 0.25 KW 230V
FRESHWATER PRESSURE PUMPS 2 X GIANNESCHI ECOJET
WATER HEATER THERMEX PO 100 100 LITS
AIR CONDITIONONG SYSTEM FRIG-IT 43,600 BTU
BATTERY CHARGER DOLFIN 24V/100 A
BATTERIES EXIDE MAXX 900 12 V
ANCHOR SANGUINETTI CHIAVARI 50 KG SC 92
ANCHOR CHAIN 100 METERS 12 mm GAUGE
WINDLASS LOFRANS PROJECT 2000 2000W 24V
WARPING WINCHES 2 X LOFRANS T 1200 1200 W 24V
ENGINE FUEL SEPARATOR FILTERS SEPAR SWK 2000/I8
GENERATORS FUEL SEPARATOR FILTERS SEPAR SWK 2000/I5
STEERINGAND AUTOPILOT HYDRAULIC BOX BCS SI 315
HATCH,GANGWAY,SWIMMING,LADDER BESENZONI PI 376.40
BOW THRUSTER SIDE-POWER SP 240 TC
STERN THRUSTER SIDE-POWER SP 200 TC
WATER MAKER IDROMAR MC2 J MINICOMPACT 130 LT/HR
AIR COMPRESSOR
UNDER WATER LIGHTS
BRIDGE EQUIPMENT
AUTOPILOT FURUNO
RADAR 3 CM FURUNO
ECHOSOUNDER FURUNO
NAVNET C-MAP NT MAX FURUNO
VHF RADIO FURUNO
KVH TRACPHONE SATELLITE
TRACVISION SATELLITE TV
GPS NAVIGATOR FURUNO
CHAIN COUNTER LOFRAN
MULTISYSTEM ALARMS MONITOR
GUEST ACCOMODATION
MASTER CABIN
ONE TV LCD 32’
ONE SATELLITE DECODER ASTON WAMBA
ONE DENON DVD PLAYER
VIP CABIN
ONE TV LCD 24’
ONE SATELLITE DECODER ASTON WAMBA
ONE DENON DVD PLAYER
GUEST CABIN
ONE TV LCD 24’
ONE SATELLITE DECODER ASTON WAMBA
ONE DENON DVD PLAYER
LOWER DECK SALON
ONE TV LCD 40”
ONE SATELLITE DECODER ASTON WAMBA
ONE DENON DVD PLAYER
MAIN SALON
ONE TV LCD 24’
ONE SATELLITE DECODER ASTON WAMBA
ONE BOSE DVD PLAYER
HERMES DINNER SET UPS
GALLEY
OVEN MIELE MULTIFUNCTION
DISHWASHER
FRIDGE BOSCH
LAUNDRY MACHINE MIELE
SAFETY DEVICE
16 LIFE JACKETS
14 THERMAL BAGS
ONE BOX (6 RED HAND FLARES,4 RED ROCKETS,2 SMOKE SIGNAL)
2 LIFE RAFT ZODIAC 6 PERSONS
2 LIFE RINGS
TENDER WILLIAMS 3.85 90 HP
JET SKI 3 SEATS YAMAHA VX V1 110 HP
2 DONUTS
WAKEBOARD
