Benetti 116 Mediterraneo Botti

Hard-top painted in dark color (as per BM Handrails and Paint Special Package).

External ceiling upgrade with teak inlay (like #BM001 M/Y Oli).

Additional large cleats on aft bathing platform for tender mooring.

Automatic sliding door for saloon main entrance on Upper Deck.

Side boarding ladder Calistri.

Garage curtain for back closure fixed with upper and lower hooks, in white PVC with ship name in black.

Manual awning on Sun Deck aft. Supply and installation of n.3 curtains in PVC, with supports.

Glass handrail throughout the yacht (as per BM Handrails and Paint Special Package).

Sun umbrella on beach platform/Sun Deck, Install 2 sockets on platform, 2 on pool, 2 on SD Aft, and 2 umbrellas overall.

Manual awning on Upper Deck fwd. Supply and installation of n.2 curtains in PVC, with support structure.

Sink in Engine room.

Yacht name on sides in stainless steel (BOTTI).

Yacht name on transom in stainless steel with backlight (BOTTI).

Fuel depuration system - Alfalaval MIB303.

Refueling pump system in the garaje.

Black water treatment system Ecomar 70.

Hand held shower on Jacuzzi casing.

Steam generator for Owner’s shower.

Custom Jacuzzi on UD fwd (like #BM001 M/Y Oli).

Domestic appliances converter 18kVA.

Power converters Atlas SPA70-70kVA.

Underwater lights (15).

Led lights in engine room.

AIS system – Furuno FA50.

Weather receiver - Sirius WX2.

Monitoring system in Captain’s Cabins 6,5” monitor.

CCTV system (3 fix cameras+ panning camera + 1 monitor extra for crew mess) 2 cameras, 1 for ER one for Cockpit to see marina, and that he can see on his ipad at home, and TV in master.

BEST audio system on Sun Deck.

External waterproof TV on Sun Deck with independent BEST system, In the middle cabinet.

Internet access-LAN server + LAN sockets (n.12) Dock WI-FI antenna.

Total WI-FI coverage, with roaming.

TV in Captain cabin LCD 22’’, fixing arm, cabling, And on crew mess.

Upgrade external speakers and amplifiers JL speakers (n.12) + JL amplifiers (n.3).

Upgrade internal speakers B&W speakers (all).

Launchport induction Ipad station.

Electrical curtains (each) Electrical cusrtains in salon MD and Salon UD.

Pullman bed in guests cabin (each) One Only.

One of the Twin bed sliding convertible in a double bed in guest cabin (each) in both cabins.

Wooden floor in LD.

Wooden floor in MD.

Wooden floor in UD.

Marble top for external GRP cabinet.

Electrical curtains on LD guests cabins for total blackout effect.

Electrical curtains on MD owner cabin for total blackout effect.

Safe for guests cabins (each) All cabins in LD.

Barbecue on Sun Deck in the top.

Ice maker isotherm IM230.

Wine cellar in Salon (16 bottles).

GENERATORS: Kohler 70EFOZDJ     Stbd: 975 hours / Port: 980 hours

A Stability information booklet containing the stability characteristics of the Yacht under standard load conditions (lightship condition, full load/departure and 10% load/arrival) will be prepared according to the Rina Rules for Pleasure Yachts.

Max speed (4):                                  15,0 knots.
Speed at 85% of max power (4):      14,0 knots.
Range at 10 knots (5):                       3200nautical miles.

· Builder's Certificate, issued by Benetti;
· International Tonnage Certificate (1969 Tonnage Convention), issued by RINA on behalf of the Flag Authority;
· Short Term Certificate of Class for Pleasure Yacht, issued by RINA;
· International Tonnage Certificate (1969 Tonnage Convention), issued by RINA on behalf of the Flag Authority;
· International Sewage Pollution Prevention Certificate (Marpol Convention Annex IV), issued by RINA on behalf of the Flag Authority;
· Statements of voluntary compliance for antifouling.

NAVIGATION COMMUNICATION AND SIGNALLING EQUIPMENT

The following controls will be provided in Wheelhouse:

· steering actuator with wheel,

· bow thruster control lever and running indicator,

· main engines throttles,

· MMEE Key, start/stop buttons and alarm signal,

· emergency stop for main engines,

· rudder angle indicator,

· fin stabilizers control panel.



The following controls will be provided in Wing stations:

Two control stations with 3.5” multifunction displays positioned externally at both sides of the wheelhouse and will include all the necessary commands and instruments for manoeuvring the Yacht in mooring operations, that is:

· steering tiller,

· slave bow thruster control lever,

· horn,

· main engine throttles,

· MMEE start/stop buttons and alarm signal, emergency stops,

· NMEA DATA.



The following equipment will be installed:

INTEGRATED NAVIGATION SYSTEM “iBridge”

Visualizing system including:

· n°2 LCD monitor (standard) 15” IP 65 marinized,

· n°2 NMEA Display 3,5”,

· n°2 cartography systems (charts excluded),

· n°2 cartography softwares.



Control system including:

· n°1 control trackball,

· n°2 touch panel control LCD 15’’, for the control of the following users:

·        radars,

·        echosounder,

·        CCTV (Option),

·        wipers,

·        horn,

·        steering pumps,

·        monitors dimming,

·        search lights,

·        steering mode,

·       monitoring system.



Navigation sensors including:

· n°1 radar, 64mn, 6KW,

· n°1 Navnet 2D BB,

· n°1 graphic depth / log transducer,

· n°1 GPS,

· n°1 overhead mounting magnetic compass for WH.



Charting plotter system including:

· n°1 chart plotter integrated with radar/echo system + charting software (charts excluded),

· n°1 independent chart system + charting software (charts excluded).



Wheather station including:

· transducers interface,

· ultrasonic wind and pressure/temperature sensor on mast

(integrated),

· integrated GPS.



Autopilot and manouvering system including:

· n°1 autopilot system, micro-processor controlled, with feedback system,

· n°1 rudder angle indicator,

· n°1 feedback unit.



INTERCOM SYSTEM

One emergency internal communication system will be fitted in:

· wheelhouse,

· engine room,

· emergency steering location.



LOG

One speed-log system. Included in integrated

navigation system.



ECHOSOUNDER

One echosounder provided with dual frequency transducer (depth, log, water temp) with PC interface for chart plotter software.

Included in integrated navigation system.



MAGNETIC COMPASS

One ceiling mounted magnetic compass in wheelhouse.



WIND SYSTEM

One wind system with no moving parts and with GPS, air temperatura and pressure sensors supplied. Included in integrated navigation system.



VHF SYSTEM

· n°1 VHF class D (wheelhouse),

· n°3 portable VHF complete of hand free kit.



X-BAND RADAR

One 6 kW- 64 nm - X band - 4 ft antenna radar provided.

Included in integrated navigation system.

One radar interface will be provided.



AUTOPILOT

One autopilot will be provided comprising of n°1 NFU tiller interface, n°1 rudder angle indicator, n°1 feedback unit. Included in integrated navigation system.



GPS SYSTEM

N°1 GPS system included in integrated navigation system.



TELEPHONE SYSTEM

N°1 VOIP telephone system for internal communications.



CHART PLOTTER

Two system for charting will be provided. Included in integrated

navigation system. Charts are not included.



HORN

A pneumatic horn will be provided (Kahlenberg T-3A Chimetone).

Controlled by the integrated navigation system.



TELEPHONE UNITS

N°13 VOIP telephones connected to the B.E.S.T network will be provided.



MONITORING SYSTEM

The system is composed by two intelligent units, one is located in the engine control room, the other is located in the wheelhouse, they are connected by redundant LAN net. One is the data back-up and recovery software for the other, assuring the total control of the system even with only one unit working.

The main system’s components are:

· n°2 Touch Panels: one 15” in wheelhouse (part of integrated navigation system) and one 15” in engine room,

· n°2 monitoring and control unit (wheelhouse and engine control room),

· field cards (I/O) (sufficient number for the proper working system),

· multiserial cards (sufficient number for the proper working system),

· n°3 cumulative alarms repeater panels (wheelhouse, engine room and crew mess ).



The main ship’s systems controlled by automation an monitoring

system are:

Power station

The system is interfaced with the electric generators and the shore

line to monitor their electric parameters and operates as supervisor of

the electric sources.

Navigation lights

Entrances monitoring

Main engines gas exhaust valves

Bilges

Tanks

Main engines

Fans and dampers

Batteries and battery chargers

Electric pumps

Alarm notification



EMERGENCY STOP SYSTEM

Main engines emergency stops provided in wheelhouse, wing stations and engine room.



MAIN ENGINES CONTROL SYSTEM

Main engines throttles provided in wheelhouse and wing stations.



ENTERTAINMENT SYSTEM

The core of the entertainment/domotics is the B.E.S.T. system which is a complete and modular solution for the distribution of digital services over a single physical infrastructure (Ethernet Cat 5E cabling).



The services generally supervisioned by B.E.S.T. system (where present) include:

Audio video functionality

Voice communication functionality



TV and Stereo Equipment

· N°1 TV/RADIO antenna system for terrestrial broadcasting reception,

· N°1 “BEST” Integrated Entertainment System.



CREW MESS

· N°1 TV 32” LCD FULL HD - 16:9

· N°1 micro Hi-Fi – AM/FM Tuner - CD player

· N°1 pair of loudspeakers



TWIN GUEST CABINS

· N°1 TV 22’’ LCD HD ready - 16:9

· N°1 AVR AM/FM Tuner

· N°1 blue ray player

· N°1 pair of loudspeakers

· N°1 integrated wi-fi remote control (iPAD mini)

· N°1 Apple TV

· N°1 iPAD minidock charge station



VIP CABINS

· N°1 TV 40” LCD FULL HD - 16:9

· N°1 AVR – AM/FM Tuner

· N°1 blue ray player

· N°1 pair of loudspeakers

· N°1 integrated wi-fi remote control (iPAD mini)

· N°1 Apple TV

· N°1 iPAD minidock charge station



CREW CABINS.

Items to be considered for three cabins.

· N° 1 car stereo - CD player

· N° 1 pair of loudspeakers



OWNER’S CABIN

· N° 1 TV 55” LED ULTRA HD - 16:9

· N°1 AVR AM/FM Tuner

· N°1 blue ray player

· N°1 “BEST” Audio-Video Client

· N°1 high quality speaker system surround 5.1 with powered subwoofer

· N°1 integrated wi-fi remote control (Mini iPad)

· N°1 mini iPad docking station

· N°1 Apple TV



GALLEY

· N°1 micro Hi-Fi – AM/FM Tuner - CD player

· N°1 pair of loudspeakers

MAIN SALOON

· N° 1 TV 55” LED ULTRA HD - 16:9

· N°1 AVR AM/FM Tuner

· N°1 blue ray player

· N°1 “BEST” audio-video client

· N°1 high quality speaker system surround 5.1 with powered subwoofer

· N°1 integrated wi-fi remote control (Mini iPad)

· N°1 mini iPad docking station

· N°1 Apple TV



MAIN SALOON DINING (slave of main saloon)

· N°1 keyboard for volume control

· N°1 pair of loudspeakers



EXTERNAL MAIN DECK (slave of main saloon)

· N°4 marine speakers

· N°1 keyboard for volume control



WHEELHOUSE

· N°1 micro Hi-Fi - AM/FM Tuner - CD player

· N°1 pair of loudspeakers



CAPTAIN CABIN

· N°1 car stereo - CD player

· N°1 pair of loudspeakers



SKY LOUNGE

· N° 1 TV 65” LED ULTRA HD - 16:9

· N°1 AVR AM/FM Tuner

· N°1 blue ray player

· N°1 “BEST” audio-video client

· N°1 high quality speaker system surround 5.1 with powered subwoofer

· N°1 integrated wi-fi remote control (Mini iPad)

· N°1 mini iPad docking station

· N°1 Apple TV



EXTERNAL UPPER DECK AFT(slave of sky lounge)

· N°1 keyboard for volume control

· N°4 marine speakers



EXTERNAL UPPER DECK FORWARD

· N°1 marine CD/mp3 Player – Radio Tuner

· N°1 airport express

· N°2 marine speakers



SUN DECK

· N°1 Marine CD/mp3 Player – Radio Tuner

· N°1 airport express

· N°4 marine speakers



SERVER RACK

· N°1 switch managed 24 ports full gigabits

· N°1 KVM controller (keyboard, mouse, lcd)

· N°1 AVoD storage system 2 Tbytes raw RAID System

· N°1 Voip Server

· N°1 UPS rack mount

· N°1 rack for devices housing



DISTRIBUTED EQUIPMENT

· N° 8 access point WiFi

· N°2 network Switches



MAIN ENGINES

MAN V12-1400, of 1029 kW (1400 mHP) @ 2100 rpm each.

Each engine will have following features:

· Cylinders and arrangement: 12 cylinders in 90°V design,



GEAR BOXES

A reduction gear box for each engine will be provided, type ZF 3310.



PROPELLERS

Two high skewed propellers designed to obtain high efficiency and low noise provided. They will be made by five nickelaluminium- bronze blades and hub.



BOW THRUSTER TUNNEL

A GRP tunnel provided and fixed to the hull.



BOW THRUSTER

An electric motor driven bow thruster (CMC BTM50) will be provided, having following features:

· Power: 52 kW/ 400VAC 3 ph

· Insulation Class of electric motor: F

· Protection degree of electric motor: IP 23

· Service factor of electric motor: S6 - 40%

· Inside tunnel diameter: about 500 mm

· Nominal thrust (without grid): 8,1 kN. A thrust reduction of 30% is expected with the installation of tunnel grids

Control joystick installed on the wheelhouse console and on

wings control panels.



STABILIZER FINS

One pair of stabilizer fins (CMC Stabilis Electra SE80-7-4-160) provided for underway operation and at anchor as well.



APPLIANCES

CREW:

LAUNDRY            WASHER MACHINE 1

LAUNDRY            DRYER MACHINE 1

CREW MESS        FRIDGE 1

CREW MESS        MICROWAVE 1



GUEST & OWNER:

GALLEY                   COOKING TOP 1

GALLEY                   EXHAUST HOOD 1

GALLEY                   OVEN 1

GALLEY                   DISHWASHER 1

GALLEY                   GARBAGE MACERATOR 1

GALLEY                   FREEZER 1

GALLEY                   FRIDGE 2

GALLEY                   TRASH COMPACTOR 1

PANTRY                  WINE CELLAR UNDER TOP TYPE 1

PANTRY                   MICROWAVE 1

SKY LOUNGE           ICE MAKER 1

SKY LOUNGE           MINIFRIDGE 1



EXTERNAL:

BAR                        ICE MAKER 1

BAR                        MINIFRIDGE 1
